General |
|
|
GPON Standards |
ITU-T G.984 |
|
Distance |
20Km Max |
|
Data Rates |
Upstream:1.25Gbps, Downstream:2.5Gbps |
|
VOIP Standards |
SIP (RFC3261), ITU-T G.729/G.722/G.711a/G.711 |
|
Hardware |
|
|
Interfaces |
1 x SC/APC GPON Port, 1 x 10/100/1000Mbps LAN Port, 1 x FXS Port |
|
Buttons |
Power ON/OFF Button, Reset Button |
|
Power Supply |
DC 12V 0.5A |
|
Dimensions (W X D X H) |
90* 73*25.2mm |
|
Software Features |
|
|
Quality of Service |
WMM, Bandwidth Control |
|
Port Forwarding |
L2/L3 forwarding, L3 NAPT |
|
VPN |
802.1Q tag VLAN, VLAN transparent mode/VLAN translation mode/VLAN trunk mode |
|
Access Control |
Local Management Control, Host List, Access Schedule, Rule Management |
|
Firewall Security |
DoS, SPI Firewall IP Address Filter/MAC Address Filter/Domain Filter IP and MAC Address Binding |
|
Management |
Access Control, Local Management, Remote Management |
|
Environment |
|
|
Operating Temperature |
0°C~40°C (32°F~104°F) |
|
Storage Temperature |
-40°C~70°C (-40°F~158°F) |
|
Relative Humidity |
10%~90%, non-condensing |
|
Storage Humidity |
5%~95%, non-condensing |
|
Package Contents |
|
|
1 x GPON Router 1 x Power Adapter 1 x Ethernet Cable |
|
|
Certifications |
|
|
CE, RoHS |
|
