General |
|
|
Wireless Standards |
IEEE802.11a/n/ac,5GHz IEEE802.11b/g/n,2.4GHz |
|
Signal Rate |
5GHz: Up to 867Mbps, 2.4GHz: Up to 300Mbps |
|
Operation Frequency |
2.4GHz 和5GHz |
|
Reception Sensitivity |
5GHz 11a 6Mbps : -96dBm, 11a 54Mbps: -79dBm 11ac HT20: -71dBm, 11ac HT40: -66dBm, 11ac HT80: -63dBm, 11n HT20: -72dBm, 11n HT40: -71dBm
2.4GHz 11g 54M: -77dBm 11n HT20: -74dBm, 11n HT40: -72dBm |
|
Wireless Sercuity |
WEP, WPA / WPA2, WPA-PSK/ WPA2-PSK encryption |
|
VOIP Standards |
SIP (RFC3261), ITU-T G.729/G.722/G.711a/G.711 |
|
Hardware |
|
|
Interfaces |
4 x 10/100/1000Mbps LAN Port, 1 X SIM Slot， 1 X Micro-USB 2.0 Port 1 x RJ11 Port |
|
Antenna |
2 x 5dBi external 2.4G antennas, 2 x 5dBi external 5G antennas |
|
Buttons |
Power ON/OFF Button, WPS/WiFi Button，Reset Button |
|
Power Supply |
DC 12V 1.5A |
|
Dimensions (长 X 宽 X 高) |
202 x 128x 35mm |
|
Software Features |
|
|
WAN Type |
Dynamic IP/Static IP/PPPoE |
|
DHCP |
Server, Client, DHCP Client List, Address Reservation |
|
Quality of Service |
WMM, Bandwidth Control |
|
Port Forwarding |
Virtual Server, Port Triggering, UPnP, DMZ |
|
VPN |
PPTP, L2TP, IPSec |
|
Access Control |
Parental Control, Local Management Control, Host List, Access Schedule, Rule Management |
|
Firewall Security |
DoS, SPI Firewall, IP Address Filter/MAC Address Filter/Domain Filter, IP and MAC Address Binding |
|
USB Sharing |
Support Samba(Storage)/FTP Server/Media Server/Printer Server/DLNA |
|
Management |
Access Control, Local Management, Remote Management |
|
Internet Protocol |
IPv4, IPv6 |
|
Environment |
|
|
Operating Temperature |
0°C~40°C (32°F~104°F) |
|
Storage Temperature |
-40°C~70°C (-40°F~158°F) |
|
Relative Humidity |
10%~90%, non-condensing |
|
Storage Humidity |
5%~95%, non-condensing |
|
Package Contents |
|
|
1 x Wireless Router 1 x Power Adapter 1 x Ethernet Cable |
|
