Wireless |
|
|
Wireless Standards |
WiFi 7 IEEE 802.11a/b/g/n/ac/ax/be |
|
Mesh Protocol |
IEE 802.11k/v/r IEEE 1905.1 |
|
Signal Rate |
5GHz：5764Mbps 2.4GHz：1376Mbps |
|
Operation Frequency |
2.4GHz&5GHz |
|
Wireless Security |
WEP, WPA, WPA2, WPA2 Mixed, WPA3, WPA3 Mixed Wireless Security: Enable / Disable WPS fast encryption |
|
Hardware |
|
|
Interfaces |
1 x 100/1000/2500/10000Mbps WAN Port 3 x 10/100/1000Mbps LAN Port 1 x USB 3.0 Port |
|
Buttons |
Power ON/OFF Button, WPS/Reset Button |
|
Power Supply |
DC 12V2A |
|
Antenna |
5×High-Performance Antennas (Internal) |
|
Dimensions (W X D X H) |
/ |
|
Software Features |
|
|
WAN Type |
Dynamic IP/Static IP/PPPoE |
|
DHCP Server |
DHCP Server； DHCP Client List¢；DHCP Reservation |
|
Quality of Service |
WMM, Bandwidth Control |
|
Virtual Server |
Port Forwarding, DMZ Host, UPnP |
|
VPN |
PPTP Client,L2TP Client |
|
Security |
Client Filter |
|
Firewall |
Forbid WAN PING from internet |
|
Internet Protocol |
IPv4&IPv6 |
|
Basic Features |
SSID Broadcast Enable / Disable |
|
Environment |
|
|
Operating Temperature |
0°C~40°C (32°F~104°F) |
|
Storage Temperature |
-40°C~70°C (-40°F~158°F) |
|
Relative Humidity |
10%~90%, non-condensing |
|
Storage Humidity |
5%~95%, non-condensing |
|
Package Contents |
|
|
1 x MB7200XE 1 x Power Adapter 1 x Ethernet Cable 1 x Quick Installation Guide |
|
|
Certifications |
|
|
CE, RoHS |
|
